    SEWO-B6-180 Swing Gate
    Number of views:
    1000

    SEWO-B6-180 Swing Gate

    Swing Turnstile Gate
    Retail price
    0.0
    元
    Market price
    0.0
    元
    Number of views:
    1000
    Product serial number
    SEWO-B6-180
    Category
    Swing Gate
    Quantity
    -
    +
    Stock:
    0
    1
    Product description
    Parameters
    Technical Parameters
    Product advantages
    Project cases

    SEWO B6 Series Swing barriers developed, researched and produced by our company are used to meet to place that highend and more width requiry. The housing comes out from stainless steels pressing which is good-looking, anti-rust and durable. It can be integrated with magnetic card, barcode, IC or ID card ,face recogination and QR Code by standard electrical interface, thus good-order and civilized passing means are realized and unauthorized persons will never be allowed to get in. Meanwhile, to meet fire-control passage requirements, swing barrier’s arms will open automatically if power off and there will be enough time to organize people to get out.

    Keyword:
    High Speed Gate
    Turnstile Gate
    We could not find any corresponding parameters, please add them to the properties table
    1. Product Name：SEWO Swing Turnstile Gate
    2. Model：SEWO-B6-180
    3. Size：L 1200*W 180*H 980mm
    4. Weight：80kg
    5. Passing Width：60cm~90cm adjustable
    6. Passing Speed：45 people/min
    7. Operating Time：0.4 second
    8. Protection Grade：IP54
    9. IR Sensor：4 pairs
    10. Temperature rise of motor：∆T15°
    11. Noise：< 50db
    12. Housing Material：SUS304 Stainless Steel
    13. Driving Motor：DC Brushless motor ( 24V,5A )
    14. Working Voltage： AC220V±10%,50Hz±4%
    15. Relative humidity：5%- 95%( no condensation )
    16. Working temperature:-15℃-70℃
    17. MCBF：Over 5,000,000 cycle

    1). Running stably without noise and mechanical impact
    2). The number of the passing persons can be counted via the built-in people counter
    3). Several ways of working modes for option
    4). Bi-direction or one direction permitted. One forbidden. Or one direction charged.
    One for free . And all the working modes set by the buttons in the main control board
    5). Beam falling and lifting can be controlled in far distance so to satisfy the special require ment of the users and the request
    of fire protection
    6). LED Direction-guide lights in the turnstile to tell you whether the direction to go or not
    7).The standard electrical interface connected with various kinds of reader and writer equipments
    8). All the functions realized in one integration machine and controlled and managed by the computer in the far distance
    9). The number of the persons passed can be counted automatically which can also be display in LED
    10). The function with or without card-reading memory can be set according to your demand
    11). Self-check and alarm for convenient to operate

    B6-180
    B6-180-7
    B6-180-3
    B6-180-9
    B6-180-6
    B6-180-5
    B6-180
    B6-180-7
    B6-180-3
    B6-180-9
    B6-180-6
    B6-180-5
