    SEWO 5311 Columnar swing gate
    Number of views:
    1000

    SEWO 5311 Columnar swing gate

    Retail price
    0.0
    元
    Market price
    0.0
    元
    Number of views:
    1000
    Product serial number
    SEWO-5311
    Category
    Swing Gate
    Quantity
    -
    +
    Stock:
    0
    1
    Product description
    Parameters
    Technical Parameters
    Product advantages
    Project cases

    　SEWO-5311 series Cylinder Swing Barrier Gate was specifically designed for persons with disabilities. It has an innovative design to enable quicker and easier passage and to fit into tight spaces. Its cabinet was designed to withstand the impact of wheel chairs and carts. It can be for one-way and two-way, pedestrian traffic control. Operation in either a 1 X 90° Or 2 X 90° Bi-directional mode. These gates are also used to complement our turnstile and optical turnstiles especially where passage of larger items is required. With an opening of up to 900mm, items such as wheelchairs, trolleys and oversized packages are easily accommodated.

        Cylinder swing Barrier Gate is suitable for both indoor and outdoor(tent). It could be wildly used in the place where intelligentized management is needed such as station, port, subway, factory, mansion, intelligent community, hotel, club, marketplace, enterprise and institution etc.

    We could not find any corresponding parameters, please add them to the properties table

    　

    1. Product Name: SEWO Columnar Swing Gate
    2. Housing Dimension: 168*1050mm
    3. Swing Arm Width: 600mm
    4. Passing Width: 1200mm
    5. Housing Material: 304 grade stainless steel
    6. Thickness of Stainless Steel:1.8mm
    7. Passing speed: 45 person/min
    8. Working Voltage: AC220V±10V, 50HZ
    9. Working temperature: -30°C--+70°C
    10. Working mode: one directional or Bi-directional
    11. Control type: IC Cards , ID Cards
    12. Warranty: 1 Year

    1. It has the function of fault self-check and alarm prompt, which is convenient for users to maintain and use.

    2: with power off automatically open, call self-check and automatically resume in the locked state

    3: with a variety of working modes to choose from, you can read the card bidirectional, or read the card on one side, the other direction ban, read the card on the other side, the other direction free passage, and the working mode can be set through the main board menu.

    4: after the pedestrian reads the valid cartoon line, the infrared detection detects that the pedestrian passes through the automatic closing gate or the pedestrian passes through the delay closing the gate, the delay of 1-60 seconds can be set by itself through the mainboard menu.

    5: with automatic reset function. When a passer fails to pass within a specified period of time after reading a valid card, the system will automatically cancel the passer's permission to pass this time, and the restricted pass time can be set by the administrator.

    6: it has the functions of 485 remote control of opening and closing gates, so as to meet users' special needs and fire safety requirements.

    7: anti-impact function, when no signal is received to open the gate, the swing arm will lock automatically;

    8: mechanical anti-clip function, when the swing arm meets resistance in the process of reset, the motor will automatically rebound or stop working within a specified time, and the force is very small, and the alarm signal will be issued at the same time;

    9: it has a unified and standard external electrical interface, which can be connected with various reading and writing devices, facilitating system integration, and can achieve remote control and management through the management computer.

    10: it has the function of reading the card with and without memory, and users can set it according to their own needs through the motherboard keyboard.

    11. Through software setting, the total number of personnel inside the site can be limited to meet the special needs of some special occasions.

    12: the whole system runs smoothly with low noise;

    SEWO-5311-04
    SEWO-5311-02
    SEWO-5311-01
    SEWO-5311-04
    SEWO-5311-02
    SEWO-5311-01

    SEWO 5311 Columnar swing gate

    Retail price
    0.0
    元
    Market price
    0.0
    元
    Number of views:
    1000
    Product serial number
    SEWO-5311
    Category
    Swing Gate
    Quantity
    -
    +
    Stock:
    0
    1
    Description
    Parameters
    Technical Parameters
    Product advantages
    Project cases

    　SEWO-5311 series Cylinder Swing Barrier Gate was specifically designed for persons with disabilities. It has an innovative design to enable quicker and easier passage and to fit into tight spaces. Its cabinet was designed to withstand the impact of wheel chairs and carts. It can be for one-way and two-way, pedestrian traffic control. Operation in either a 1 X 90° Or 2 X 90° Bi-directional mode. These gates are also used to complement our turnstile and optical turnstiles especially where passage of larger items is required. With an opening of up to 900mm, items such as wheelchairs, trolleys and oversized packages are easily accommodated.

        Cylinder swing Barrier Gate is suitable for both indoor and outdoor(tent). It could be wildly used in the place where intelligentized management is needed such as station, port, subway, factory, mansion, intelligent community, hotel, club, marketplace, enterprise and institution etc.

    Scan the QR code to read on your phone
    We could not find any corresponding parameters, please add them to the properties table

    　

    1. Product Name: SEWO Columnar Swing Gate
    2. Housing Dimension: 168*1050mm
    3. Swing Arm Width: 600mm
    4. Passing Width: 1200mm
    5. Housing Material: 304 grade stainless steel
    6. Thickness of Stainless Steel:1.8mm
    7. Passing speed: 45 person/min
    8. Working Voltage: AC220V±10V, 50HZ
    9. Working temperature: -30°C--+70°C
    10. Working mode: one directional or Bi-directional
    11. Control type: IC Cards , ID Cards
    12. Warranty: 1 Year

    1. It has the function of fault self-check and alarm prompt, which is convenient for users to maintain and use.

    2: with power off automatically open, call self-check and automatically resume in the locked state

    3: with a variety of working modes to choose from, you can read the card bidirectional, or read the card on one side, the other direction ban, read the card on the other side, the other direction free passage, and the working mode can be set through the main board menu.

    4: after the pedestrian reads the valid cartoon line, the infrared detection detects that the pedestrian passes through the automatic closing gate or the pedestrian passes through the delay closing the gate, the delay of 1-60 seconds can be set by itself through the mainboard menu.

    5: with automatic reset function. When a passer fails to pass within a specified period of time after reading a valid card, the system will automatically cancel the passer's permission to pass this time, and the restricted pass time can be set by the administrator.

    6: it has the functions of 485 remote control of opening and closing gates, so as to meet users' special needs and fire safety requirements.

    7: anti-impact function, when no signal is received to open the gate, the swing arm will lock automatically;

    8: mechanical anti-clip function, when the swing arm meets resistance in the process of reset, the motor will automatically rebound or stop working within a specified time, and the force is very small, and the alarm signal will be issued at the same time;

    9: it has a unified and standard external electrical interface, which can be connected with various reading and writing devices, facilitating system integration, and can achieve remote control and management through the management computer.

    10: it has the function of reading the card with and without memory, and users can set it according to their own needs through the motherboard keyboard.

    11. Through software setting, the total number of personnel inside the site can be limited to meet the special needs of some special occasions.

    12: the whole system runs smoothly with low noise;
